Chauvet Professional Colordash Par-Quad 7
Chauvet Professional Colordash Par-Quad 7

Chauvet Professional Colordash Par-Quad 7

by Chauvet Professional
$416.00
Item #: CDPQ7
This product qualifies for Free Shipping
Found it cheaper? We will Price Match
Customer Service: (800) 245-6630
Product Highlights
  • 7 Quad-Color (RGBA) LEDs
  • Ultra-Compact Fixture with Split-Yoke Bracket
  • Stand Alone Color Mixing
  • Automated Programs
  • LEDs Rated at 50,000 Hours

Powered by seven quad-color RGBA LEDs, the ultra-compact COLORdash Par-Quad 7 fits in places where other fixtures cannot. The seven LEDs project deeply saturated output and any variation of white, without multi-color shadows. A split-yoke bracket eliminates the need for floor stands. Power linking with Neutrik powerCON in and out connectors, and 3- and 5-pin DMX connectors ease connections and setup. COLORdash Par-Quad 7 also includes a built-in gel frame holder.

Product Features:

  • 4, 6 or 10 DMX channels
  • Silent flicker-free operation
  • Lightweight, easy to install
  • Metal construction for added durability
  • DMX Channels: 4, 6 or 10
  • Data Connectors: 3- and 5-pin XLR
  • Light Source: 7 LEDs (quad-color RGBA) 7 W, (500 mA), 50,000 hours life expectancy
  • Shutter/Strobe: Electronic
  • Strobe Rate: 0 to 20 Hz
  • Standalone Color Mixing
  • Color Temperature Presets
  • Installed Optics: 20°
  • Beam Angle: 18°
  • Field Angle: 32.5°
  • Dimming Modes: 4
  • Illuminance: 434 lux @ 5 m
  • Color Temperature (range): 2800 to 10000 K
  • IP Rating: IP20, dry location
  • Cable Length: 5 ft (1.5 m)
  • Power Connection: Edison plug to Neutrik powerCON
  • Power Input: Neutrik powerCON
  • Power Output: Neutrik powerCON
  • Power Linking: 21 units @ 120 V; 36 units @ 208 V; 39 units @ 230 V
  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current: 73 W, 0.60 A @ 120 V, 60 Hz
  • Power and Current: 73 W, 0.36 A @ 208 V, 50 Hz
  • Power and Current: 74 W, 0.35 A @ 230 V, 50 Hz
  • 9.9" x 9" x 3.9", 5.4 lbs
  • Approvals: CE, MET

Documentation:

Manual
COLORdash Par-Quad 7 User Manual
Quick Reference Guide
COLORdash Par-Quad 7 Quick Reference Guide
